Solid Waste Sorting Machine 20T/D Waste Recycling Machine Customized

Name: Solid Waste Sorting Machine 20TD Waste Recycling Machine Customized
Brand: Xrido
Price: 1 USD

Wholesale Solid Waste Sorting Machine 20T/D Waste Recycling Machine Customized from china suppliers

Certification : CE ISO

Brand Name : Xrido

Model Number : Customizable

MOQ : 1 set

Delivery Time : 5-30 word days

place of origin : Henan, China

brand name : Xrido

model number : 200

type : Waste Sorting System

warranty : 1 Year

material : wooden box

machinery test report : Provided

video outgoing-inspection : Provided

core components : motor, PLC

weight (kg) : 31000

Power : 90 KW, 60 KW, 20 kw, 70 KW

Name : Waste Sorting System

Application : Solid Waste

Function : Garbage Recycling Sorting

Color : Customized Color

Advantage : Easy Operation High Efficiency

Voltage : 220V/380V/415V/440V/customized

Capacity : 20t/d

Package : Carton Box

After Sale Service : Overseas

Contact Now

20T/D Municipal Solid Waste Sorting Treatment Machinery System Municipal Waste Sorting Machine

Product characteristics

The domestic waste sorting line integrates AI visual recognition and mechanical sorting technology. When the material flows through the spectral sorter, the near-infrared sensor instantly identifies the plastic material, and the high-pressure airflow accurately blows it off the conveyor belt. The magnetic separation equipment uses adjustable magnetic field strength to classify and recycle metals with different magnetic properties. At a transfer station in Hangzhou, the sorting line has achieved a purity of 98% for recyclables, increasing carbon emissions by about 4,500 tons per year, equivalent to planting 250,000 more trees.

Solid Waste Sorting Machine 20T/D Waste Recycling Machine Customized

‌Waste Recycling Production Line Workflow‌

‌Initial Feeding Stage‌
- A forklift delivers the waste materials to the feeding platform, where a hopper collects and transfers them into the system.
‌Distribution & Conveying‌
- A feeder evenly spreads out the waste, which is then transported via a conveyor belt to the next stage for further processing.
‌Manual Sorting‌
- As the waste moves along the manual sorting platform, workers remove oversized items such as large branches, sticks, bricks, bottles, and other non-processable debris.
‌Mechanical Separation‌
- A rotating screening machine divides the waste into two categories based on size:
  - ‌Over 50mm‌ (hole size optimized for real-world waste composition): Includes recyclable items like plastic bottles, shoe soles, and similar materials.
  - ‌Under 50mm‌: Primarily consists of fine metal fragments.
- A high-strength magnetic separator further extracts ferrous metals from the waste stream.
‌Final Processing & Recycling‌
- ‌Plastics‌ are compacted using a baler for easy storage and transport.
- ‌Heavy non-recyclable waste‌ is either sent directly to landfills or crushed for alternative uses (e.g., brick production).
- ‌Mixed materials‌ undergo additional sorting to recover any remaining reusable components before recycling.

This structured approach ensures efficient waste segregation, maximizes resource recovery, and minimizes landfill dependency. Let me know if you'd like any modifications!

Waste sorting production line:
Urban waste, construction waste, or stale waste enters the feeder --Bag breaking machine--Belt conveyor --Waste trommel screen machine -- Magnetic separator --Integrated air separator-- Manual sorting platform -- Garbage packaging system -- Waste shredder machine.

Product Paramenters

Model	XRD-100D	XRD-200D	XRD-400D
Raw materials	Domestic Waste, Urban trash , Landfill Stale Waste, Municipal Solid Waste, Construction and Decoration Waste, Scrap Metal, Industrial Waste, Plastic Waste, Solid Waste
Capacity	100T/D	200T/D	400T/D
Power	149KW	224.7KW	279KW
Area	2400㎡	2800㎡	3000㎡
Working time	20 hours	20 hours	20 hours

*This is the basic model of our waste sorting machine. Our factory manufactures customized machines according to the different requirements of different customers.

Customer Site

Certifications

FAQ

Q: Do you accept Custom-made? A: Yes, we can custom the Tire Shredder machine according to clients requirements.
Q: How can i get a suitable Tire Shredder machine?
A: Tell us your requirements, such as raw material, out put size, capacity etc, our engineer can recommend the suitable configuration and provide quotation for you.
Q: How long is your delivery time ?
A: 1 set for normal machine needs about 5 working days, if 1 or more containers, needs about 20 working days.
Q: How long is the warranty?
A: 1 year since the date of shipment, if parts failure or damage(because of the quality problem, except wearing parts), our company will provide these parts for free.
Q:What is your payment term?
A: T/T 100% before shipment, L/C at sign, or Trade Assurance order recommended.
